Brand Name: | Trixon |
Model Number: | TQS-FG10-30DCR |
MOQ: | Negotiable |
Price: | Negotiable |
Packaging Details: | Negotiable |
Payment Terms: | L/C D/P |
Trixon 40G 10km QSFP+ ER4 Transceiver products is a 4x10G hot pluggable optical transceiver. The optical connectivity is based on two SMF LC connectors, one for Tx and one for Rx. The Tx and Rx each consist of 4 10GB/s CWDM channels, whose wavelengths are in the 1300nm range. The QSFP+-LR4 and ER4 transceiver is designed for applications based on the IEEE802.3ba 40GBASE-LR4 standard of up to 10km, 40GBASE-ER4 standard of up to 40km reach.
Product Name | Technical Parameters | ||||
---|---|---|---|---|---|
40G QSFP+ Transceiver | Distance: 10km Fiber Type: Single-Mode Connector: LC DDM: Support Data Rate: 40Gbps Wavelength:
|
Parameter | Symbol | Min | Typ. | Max | Unit |
Transmitter | |||||
Centre Wavelength | λc | 1264.5 | 1271 | 1277.5 | nm |
1284.5 | 1291 | 1297.5 | |||
1304.5 | 1311 | 1317.5 | |||
1324.5 | 1331 | 1337.5 | |||
Spectral Width (-20dB) | Δλ | - | - | 1 | nm |
Transmitter Signal Rate | 11.2 | Gbps | |||
SMSR | 30 | dB | |||
TDP, each Lane | TDP | 2.6 | dB | ||
Optical Return Loss Tolerance | TOL | 20 | dB | ||
Average Output Power | Pout | -7 | - | 2.3 | dBm |
Extinction Ratio | ER | 6 | - | - | dB |
Output Optical Eye | Compliant With IEEE Std 802.3ba-2010 |
Parameter | Symbol | Min | Typ. | Max | Unit |
Receiver | |||||
Centre Wavelength | λc | 1264.5 | 1271 | 1277.5 | nm |
1284.5 | 1291 | 1297.5 | |||
1304.5 | 1311 | 1317.5 | |||
1324.5 | 1331 | 1337.5 | |||
Receiver Sensitivity*note5 | SEN | - | - | -11.5 | dBm |
Receiver Overload | Pmax | 2.3 | - | - | dBm |
LOS De-Assert | LOSD | - | - | -11.5 | dBm |
LOS Assert | LOSA | -20 | - | - | dBm |
LOS Hysteresis | LOSH | 0.5 | - | 5 | dB |
Data Centers: The TQS-FG10-30DCR transceiver can be used in data centers to support high-speed and efficient data transfer between network switches, routers, and servers. It enables the transmission of large volumes of data, facilitating rapid communication and data processing within the data center infrastructure.
Cloud Computing: In cloud computing environments, where massive amounts of data need to be transmitted and processed, the TQS-FG10-30DCR transceiver can play a crucial role. It facilitates fast and reliable connectivity between cloud servers, storage systems, and networking equipment, ensuring smooth data flow and efficient cloud service delivery.
High-Performance Computing (HPC): HPC clusters and supercomputers require high-speed interconnects to enable fast communication between computing nodes. The TQS-FG10-30DCR transceiver can be employed in HPC environments to support high-performance data transfer, improving the overall efficiency and performance of computational tasks.
Telecommunications and Service Providers: The TQS-FG10-30DCR transceiver can find applications in telecommunications networks and service provider environments. It enables efficient data transfer between network equipment, facilitating high-speed communication for voice, data, and multimedia services.
Video Streaming and Broadcasting: With its high data rate, the TQS-FG10-30DCR transceiver is suitable for video streaming and broadcasting applications. It allows for the transmission of high-quality video signals over long distances, ensuring smooth and uninterrupted video delivery for media content distribution.
Enterprise Networking: The transceiver can be utilized in enterprise networking environments, connecting network switches, routers, and other network devices. It supports fast and reliable data transfer, enabling efficient communication and collaboration across different departments or locations within an organization.
Transmission Distance: The standard TQS-FG10-30DCR transceiver has a transmission distance of 10km. Customization options are available to accommodate longer or shorter distance requirements by optimizing components and power levels, or incorporating specialized amplification techniques.
Connector Type: The TQS-FG10-30DCR transceiver comes with a standard LC connector, but customization options can be explored for different connector types like SC or MPO to suit your network infrastructure.
Temperature Range: Customization options can be discussed to ensure the transceiver's performance and reliability in extreme temperature conditions, such as selecting components with extended temperature tolerances or incorporating additional thermal management features.
Protocol Support: The TQS-FG10-30DCR transceiver supports 40Gbps data transmission, but customization options can be explored to ensure compatibility with specific protocols such as Ethernet, Fibre Channel, or InfiniBand.
Power Consumption: Customization options can be discussed to optimize the transceiver's power efficiency, including adjusting power levels, optimizing circuit design, or incorporating power-saving features based on your application's power consumption requirements.
We offer comprehensive technical support and service for 40G QSFP+ Transceiver products. Our technical support team is available 24/7 to answer any questions you may have. We also provide regular updates and bug fixes for our products, ensuring that your 40G QSFP+ Transceiver is always running smoothly.
We offer a wide range of maintenance and repair services to help you keep your 40G QSFP+ Transceiver in peak condition. Our technicians are experienced in troubleshooting and repairing any issues you may have with your product. We also offer up-to-date technical advice and product information to help you get the most out of your 40G QSFP+ Transceiver.
If you ever need help with your 40G QSFP+ Transceiver, our team of experienced professionals is here to assist. We offer phone and email support to answer any questions you may have, as well as on-site service and repair if necessary. We are committed to providing you with the best technical support, so you can rest assured that your 40G QSFP+ Transceiver will always be functioning at its best.
The 40G QSFP+ Transceiver is carefully packaged in an antistatic bag, with a foam pad to protect the module from any physical damage.
The 40G QSFP+ Transceiver is shipped using a reliable third-party carrier, with tracking number provided upon request.
Reference Datasheet file code:DS180003(40G QSFP+ LR4/ER4)
