TQS-HG02-31DCR CWDM4 2km Reach,1310nm, 100G QSFP28 Transceiver for Long-Distance Applications
The 100G QSFP28 Transceiver is the perfect choice for data center and enterprise networks. It provides a high-speed, low-power, reliable connection over single-mode fiber, with a 1310nm wavelength and a temperature range of 0~70°C. It features a QSFP28 connector. This 100G QSFP28 Transceiver delivers up to 100G of data rate, enabling high-speed data transmission and a reliable connection. It is ideal for 100G Ethernet, OTN, Fibre Channel, Infiniband, and other applications. It is suitable for both short- and long-distance network applications. This 100G QSFP28 Transceiver provides reliable operation and superior performance for data centers and enterprise networks.
| Product Name | 100G QSFP28 Transceiver |
|---|---|
| Temperature | 0~70°C |
| Wavelength | 1310nm |
| DDM | YES |
| Warranty | 3 Years |
| Data Rate | 100G |
| Distance | 2km |
| Fiber Type | SIngle-Mode |
| Connector | QSFP28 |
| Parameter | Symbol | Min | Typ. | Max | Unit |
| Transmitter | |||||
| Center Wavelength | λ |
1264.5 1284.5 1304.5 1324.5 |
1277.5 1297.5 1317.5 1337.5 |
nm | |
| Side-mode Suppression ratio | SMSR | 30 | - | - | dB |
| Average Optical Power, each Lane | Pavg | -4 | - | +2.5 | dBm |
| Optical Modulation Amplitude (OMA) | Poma | -2 | - | - | dBm |
| TDP, each Lane | - | - | 3 | dB | |
| Extinction Ratio | ER | 3.5 | - | - | dB |
| Transmitter Eye Mask Definition | Complied with IEEE802.3bm | ||||
| Average Launch Power OFF Transmitter, each Lane | Poff | - | - | -30 | dBm |
| Receiver | |||||
| Center Wavelength | λ |
1264.5 1284.5 1304.5 1324.5 |
1277.5 1297.5 1317.5 1337.5 |
nm | |
| Average Power at Receiver Input, each Lane | -10.0 | - | 2.5 | dBm | |
| Receiver Reflectance | - | - | -12 | dB | |
| Los Assert | LosA | -24 | - | -13.6 | dBm |
| Los Dessert | LosD | - | - | -11.6 | dBm |
| Los Hysteresis | LosH | 0.5 | - | - | dB |
The Trixon 100G QSFP28 Transceiver (Model Number: TQS-HG02-31DCR) is a reliable and high-performance transceiver manufactured in China. It supports a data rate of 100G and utilizes single-mode fiber with a wavelength of 1310nm. This transceiver is versatile and can be applied in various scenarios, including Cloud Computing, High-Definition Video Streaming, Storage Networks, Data Centers, and High-Performance Computing. It is designed to operate in a wide temperature range from 0°C to 70°C, making it suitable for different environments.
Compliant with IEEE 802.3ba standards, the Trixon 100G QSFP28 Transceiver supports multiple data transmission protocols such as Fibre Channel, InfiniBand, and Ethernet. Its low power consumption and superior optical performance make it ideal for long-distance transmission. Additionally, it is easy to install and compatible with existing fiber-optic networks, providing convenience and flexibility.
With its exceptional performance and compatibility, the Trixon 100G QSFP28 Transceiver finds extensive applications in various fields, including Cloud Computing, High-Definition Video Streaming, Storage Networks, Data Centers, and High-Performance Computing. It enables high-speed and large-capacity data transmission, meeting the demands of modern communication networks.
We provide comprehensive technical support and service for 100G QSFP28 Transceiver. Technical support includes comprehensive product setup, hardware installation, configuration, troubleshooting, and maintenance.
We also offer software support, including software updates, patches, and upgrades. Additionally, our technical support team is available 24/7 to answer any questions you may have about the product.
For hardware maintenance and repair, we provide on-site service and can send qualified technicians to your location to diagnose and repair any hardware issues. If necessary, we can also arrange for a replacement of the hardware.
If you need additional technical assistance, we can provide on-site or remote technical support, as well as phone and email support. We also offer online tutorials and troubleshooting guides on our website.
The 100G QSFP28 Transceiver is packaged in a cardboard box for shipping. The box is designed to provide protection against bumps and impacts, as well as moisture and dust. It also includes a foam insert to provide extra protection for the product. The box measures approximately 10”x10”x6”.
The 100G QSFP28 Transceiver is shipped with a tracking number. Customers will be notified of their tracking number via email once their order has been shipped. We use standard ground shipping services for all of our shipments, and shipping times may vary depending on the destination.
We take great care to ensure that the 100G QSFP28 Transceiver is packaged and shipped securely. If you have any questions or concerns about the packaging and shipping of this product, please contact us and we will be happy to help.
Reference Datasheet file code:DS180008 (100G QSFP28 CWDM4)
