TPS-TG80-55DIR 10G SFP+ Transceiver Module, 80km,1550nm-EML,-40℃~+85℃,Industry Temperature,
The 10G SFP+ Transceiver Module is a Small Form-Factor Pluggable Plus Transceiver Module, specifically designed for high-speed communication links that require 10G bandwidth. It is equipped with Duplex LC Connector Interface and is compatible with SMF (Single-Mode Fiber) cables. It features a wavelength of 1310nm-DFB, allowing for efficient and reliable data transmission. This module is also DDM/DOM (Digital Diagnostic Monitoring) enabled, providing greater accuracy and reliability in its performance. The 10G SFP+ Transceiver Module is an ideal choice for any 10G network application.
| Properties | Details |
|---|---|
| Fiber Type | SMF |
| Wavelength | 1550nm-EML |
| Distance | 80km |
| Product Name | 10G SFP+ Transceiver Module |
| DDM/DOM | Yes |
| Compliant | Compliant With MSA SFP Specification |
| Temperature Range | -40℃~+85℃ |
| Data Rate | Operating Data Rate Is 11.3Gbps |
| Optical Interface | Duplex LC Connector Interface |
Performance Specifications – Optical
(1550nm EML and APD,80km)
| Parameter | Symbol | Min | Typ. | Max | Unit |
| Transmitter | |||||
| Centre Wavelength | λc | 1530 | - | 1565 | nm |
|
Side Mode Suppression Ratio |
SMSR | 30 | - | - | dB |
| Spectral Width (-20dB) | Δλ | - | - | 0.3 | nm |
| Average Output Power*note13 | Pout | 0 | - | 4 | dBm |
| Extinction Ratio | ER | 3.5 | - | - | dB |
| Average Power of OFF Transmitter | Pout-off | - | - | -30 | dBm |
| Transmitter Dispersion Penalty | TDP | - | - | 3.0 | dB |
| Optical Return Loss Tolerance | ORLT | - | - | 21 | dB |
| Output Optical Eye | Compliant with IEEE802.3ae-2005 | ||||
| Receiver | |||||
| Centre Wavelength | λc | 1260 | - | 1570 | nm |
| Receiver Sensitivity*note14 | SEN | - | - | -23 | dBm |
| Receiver Overload | Pmax | -7 | - | - | dBm |
| LOS De-Assert | LOSD | - | - | -24 | dBm |
| LOS Assert | LOSA | -36 | - | - | dBm |
| LOS Hysteresis | LOSH | 0.5 | - | 4 | dB |
Note13: Output is coupled into a 9/125um SMF. The typical value is +2dBm.
Note14: Measured with a PRBS 231-1 test pattern @10.3125Gbps, BER≤10-12.
Trixon TPS-TG80-55DIR SFP+ Transceiver Module is a Small Form-Factor Pluggable Plus Transceiver Module with a Duplex LC Connector Interface. It is compliant with MSA SFP Specification, with a Fiber Type of SMF and a Wavelength of 1310nm-DFB. It has a Temperature Range of -40℃~+85℃.
The Trixon TPS-TG80-55DIR SFP+ Transceiver Module is designed for various applications and scenarios, such as optical communication networks, data centers and enterprise networks. It can be used in 10 Gigabit Ethernet (10G), Fibre Channel and InfiniBand applications. It is suitable for short-range, high-speed interconnects, including switches and routers.
The Trixon TPS-TG80-55DIR SFP+ Transceiver Module offers a cost-effective solution for data center, enterprise, and storage applications. It is one of the most reliable and cost-effective solutions for high-speed interconnects. It is a great choice for customers who need to expand their network bandwidth and performance.
Connector Type: The module may come with a specific connector type, such as LC or SC. If you require a different connector type to match your existing infrastructure, you can discuss the possibility of customizing the connector type with the manufacturer.
Compatibility: If you have compatibility concerns with your existing equipment or network setup, you can discuss with the manufacturer to ensure that the customized module will be compatible with your specific environment. This may involve adjusting parameters or configurations to ensure seamless integration.
Labeling and Branding: If you require specific labeling or branding on the module, such as custom logos or serial numbers, you can discuss these customization options with the manufacturer. They may be able to accommodate your branding requirements.
Power Budget: If you have specific power budget requirements for your network, you can discuss with the manufacturer to determine if the module can be customized to meet those requirements. This may involve adjusting the power consumption or sensitivity of the module.
Testing and Certification: If you require additional testing or certification for the module to meet specific industry standards or compliance requirements, you can discuss these customization needs with the manufacturer. They may be able to provide tailored testing or certification processes.
The technical support and services for SFP+ Transceiver Module include:
Reference Datasheet File code: DS090010
