TPD-TG80-XXDCR 10.3G SFP+ DWDM EML and PIN Transceiver Module 80km,EML ,0C - 70C
The SFP+ Transceiver Module is an advanced, high-performance transceiver module designed for use in data centers, telecom networks, and enterprise networking applications. It is compliant with the SFF-8431 and SFF-8432 standards and provides a duplex LC connector interface. This module supports data transmission rates of up to 10Gbps and is available in all C-Band wavelengths on the 100GHz DWDM ITU Grid.
The SFP+ transceiver module features a small form-factor pluggable plus (SFP+) design and is designed to meet the increasing demand for higher data rates, higher density, and improved performance. It is suitable for applications such as 10G Ethernet, Fibre Channel, and InfiniBand. It also provides low power consumption and is backward compatible with earlier versions of the SFP transceiver.
The SFP+ transceiver module is an ideal solution for data centers and enterprise networking applications that require high throughput, low latency, and robust performance. It is an ideal choice for network administrators looking to upgrade their networking infrastructure and reduce power consumption.
| Parameter | Specification |
|---|---|
| Product Name | SFP+ DWDM Transceiver Module |
| Connector Type | Duplex LC Connector Interface |
| Data Rate | 10Gbps |
| Compliant | Compliant With SFF-8431 And SFF-8432 |
| Distance | 80km |
| DDM/DOM | Yes |
| Fiber Type | Single-Mode |
| Temperature Range | 0℃ ~+70℃ |
| Laser | Cooled 1550nm DWDM EML Laser |
| Wavelength | Available In All C-Band Wavelengths On The 100GHz DWDM ITU Grid |
| (XX) Value | Channel |
Frequency (THz) |
Wavelength (nm) |
(XX) Value | Channel |
Frequency (THz) |
Wavelength (nm) |
| A0 | C13 | 191.3 | 1567.13 | C5 | C38 | 193.8 | 1546.92 |
| A1 | C14 | 191.4 | 1566.31 | C6 | C39 | 193.9 | 1546.12 |
| A2 | C15 | 191.5 | 1565.50 | C7 | C40 | 194.0 | 1545.32 |
| A3 | C16 | 191.6 | 1564.70 | C8 | C41 | 194.1 | 1544.53 |
| A4 | C17 | 191.7 | 1563.86 | C9 | C42 | 194.2 | 1543.73 |
| A5 | C18 | 191.8 | 1563.05 | D0 | C43 | 194.3 | 1542.94 |
| A6 | C19 | 191.9 | 1562.23 | D1 | C44 | 194.4 | 1542.14 |
| A7 | C20 | 192.0 | 1561.42 | D2 | C45 | 194.5 | 1541.35 |
| A8 | C21 | 192.1 | 1560.61 | D3 | C46 | 194.6 | 1540.56 |
| A9 | C22 | 192.2 | 1559.79 | D4 | C47 | 194.7 | 1539.77 |
| B0 | C23 | 192.3 | 1558.98 | D5 | C48 | 194.8 | 1538.98 |
| B1 | C24 | 192.4 | 1558.17 | D6 | C49 | 194.9 | 1538.19 |
| B2 | C25 | 192.5 | 1557.36 | D7 | C50 | 195.0 | 1537.40 |
| B3 | C26 | 192.6 | 1556.55 | D8 | C51 | 195.1 | 1536.61 |
| B4 | C27 | 192.7 | 1555.75 | D9 | C52 | 195.2 | 1535.82 |
| B5 | C28 | 192.8 | 1554.94 | E0 | C53 | 195.3 | 1535.04 |
| B6 | C29 | 192.9 | 1554.13 | E1 | C54 | 195.4 | 1534.25 |
| B7 | C30 | 193.0 | 1553.33 | E2 | C55 | 195.5 | 1533.47 |
| B8 | C31 | 193.1 | 1552.52 | E3 | C56 | 195.6 | 1532.68 |
| B9 | C32 | 193.2 | 1551.72 | E4 | C57 | 195.7 | 1531.90 |
| C0 | C33 | 193.3 | 1550.92 | E5 | C58 | 195.8 | 1531.12 |
| C1 | C34 | 193.4 | 1550.12 | E6 | C59 | 195.9 | 1530.33 |
| C2 | C35 | 193.5 | 1549.32 | E7 | C60 | 196.0 | 1529.55 |
| C3 | C36 | 193.6 | 1548.51 | E8 | C61 | 196.1 | 1528.77 |
| C4 | C37 | 193.7 | 1547.72 | E9 | C62 | 196.2 | 1527.99 |
Telecommunications Networks: The module can be used in telecommunications networks to enable high-capacity and long-distance data transmission. It allows service providers to expand their network reach and offer reliable connectivity to customers over extended distances.
Data Center Interconnects: It is suitable for interconnecting data centers that are located far apart. The module enables high-bandwidth and low-latency communication between data centers, supporting the efficient transfer of large volumes of data.
Metropolitan Area Networks (MANs): MANs connect various locations within a city or metropolitan area. The TPD-TG80-XXDCR module can be used in MANs to establish high-speed and long-distance connections, facilitating efficient communication between different sites.
Wide Area Networks (WANs): WANs connect geographically dispersed locations, such as offices, branches, or data centers. The module allows for high-speed and reliable data transmission over long distances, supporting efficient communication and collaboration between remote locations.
Fiber to the x (FTTx): The module can be deployed in FTTx networks, such as Fiber to the Home (FTTH) or Fiber to the Business (FTTB), to provide high-speed broadband services over long distances. It enables service providers to deliver high-bandwidth connections to residential and commercial customers.
Wireless Backhaul: It can be used in wireless network infrastructure for backhauling data from remote locations to the core network over long distances. The module supports high-capacity data transmission, essential for supporting the increasing demand for mobile data and connectivity.
Wavelength Selection: DWDM technology allows for multiple wavelengths within the C-Band spectrum (typically 1525nm to 1565nm) to be used for optical communication. If you have specific wavelength requirements within the C-Band, you can discuss your wavelength selection with the manufacturer. They may offer customization options to match your desired wavelengths.
Distance: The standard TPD-TG80-XXDCR module has a distance capability of 80km. If you require a longer or shorter transmission distance, you can discuss your requirements with the manufacturer to explore the availability of customized options.
Temperature Range: If the standard temperature range of 0°C to +70°C does not meet your operational environment, you can inquire about the possibility of customizing the temperature range to better suit your specific conditions.
Connector Type: The module may come with a specific connector type (e.g., LC, SC). If you require a different connector type to match your existing infrastructure, you can discuss the possibility of customization with the manufacturer.
Power Budget: If you have specific power budget requirements for your network, you can discuss with the manufacturer to determine if the module can be customized to meet those requirements.
Compatibility: If you have compatibility concerns with your existing equipment or network setup, you can discuss with the manufacturer to ensure that the customized module will be compatible with your specific environment.
We offer technical support and service for our SFP+ Transceiver Module. Our technical support team is available to answer any questions you may have about our products and services.
We provide a range of services to help you get the most out of your SFP+ Transceiver Module. Our services include installation, troubleshooting, and configuration assistance.
We also offer a variety of support options, from online support and live chat to phone and email support. Our knowledgeable technical support staff are on hand to answer your questions and provide assistance.
If you need help with your SFP+ Transceiver Module, please contact us for more information.
Reference Datasheet File code: DS210003
SFP+ Transceiver Module Packaging and Shipping
The SFP+ Transceiver Modules are packed in secure, anti-static designed packaging that is designed to protect the modules from external damage and to prevent any damage caused during transit. All modules are marked with a unique serial number to ensure that the modules are shipped correctly.
Shipping of the SFP+ Transceiver Modules is done through a reputable courier service, with tracking numbers provided for each shipment. All modules are securely packaged with bubble wrap and other cushioning material to ensure that they arrive in pristine condition to their destination.
