100GBASE QSFP28 Transceiver 40km Distance ER4 0~70°C 1310nm with DDM TQS-HG40-31DCR
The 100G QSFP28 Transceiver is a high-performance, low-power optical transceiver that supports up to four independent LAN-WDM channels, each with a data rate of 25G. It features DDM (Digital Diagnostics Monitoring) to monitor optical transceiver performance in real-time. The QSFP28 connector ensures a reliable connection, allowing the transceiver to be used in high-density applications. It requires only a single +3.3V power supply, making it an ideal solution for data center and enterprise networks. The product name of this transceiver is 100G QSFP28 ER4 Transceiver.
| Attribute | Parameter |
|---|---|
| Applications | 100GBASE ER4 100G Ethernet |
| Data Rate | 100G |
| Channel | 4 Independent LAN-WDM Channels 4*25G |
| Low power consumption | < 4.5W |
| Operating case temperature | 0~70°C |
| Connector | QSFP28 |
| Wavelength | 1310nm |
| Power | Single +3.3V Power Supply |
| Fiber Type | Single-Mode |
| Distance | 40km |
Trixon TQS-HG40-31DCR 100G QSFP28 transceiver is designed for 100GBASE Ethernet applications. It is a pluggable optical module for high-speed data transmission over single-mode fiber. With a data rate up to 100G, this module supports a maximum link length of up to 40km on G.652 single-mode fiber. It is also equipped with Digital Diagnostic Monitoring (DDM) capabilities to enable real-time monitoring of transceiver parameters. This module is compliant with the Multi-Source Agreement (MSA) and IEEE 802.3ba standards.
The operating case temperature of this 100G QSFP28 transceiver is 0~70°C, making it suitable for deployment in harsh environments. In addition, it is RoHS compliant and is designed to meet all safety and EMI requirements. With its high-performance and reliable design, Trixon TQS-HG40-31DCR 100G QSFP28 transceiver is ideal for 100G Ethernet applications in data centers, enterprise networks, and telecom networks.
Brand Name: Trixon
Model Number: TQS-HG40-31DCR
Place of Origin: CHINA
Wavelength: 1310nm
Data Rate: 100G
Power: Single +3.3V Power Supply
Operating case temperature: 0~70°C
Applications: 100GBASE ER4 100G Ethernet
Trixon 100G QSFP28 Transceiver delivers superior performance with 100G data rate over single-mode fiber. It is designed for use in 100GBASE ER4 100G Ethernet applications. It supports single +3.3V power supply and operates temperature range from 0 to 70 degrees Celsius.
100G QSFP28 Transceiver Technical Support and Service
We provide technical support and service for 100G QSFP28 Transceiver. Our experienced technical team is available to answer all of your questions and provide guidance in the installation and troubleshooting of the product. We have a comprehensive knowledge base of the product, including installation instructions, FAQs, troubleshooting tips, and more.
We also provide product updates and upgrades, so that you can stay on top of the latest advancements in the product. We offer a 30-day money-back guarantee if you are not satisfied with the product, and we are committed to providing top-notch customer service and support.
