TQS-HG30-31DCR 1310nm 30km Wavelength 100G QSFP28 Transceiver,ER4 Lite,0~70°C
The 100G QSFP28 Transceiver is a high-performance optical transceiver module designed for 100G Ethernet links over single-mode fiber. It uses the QSFP28 form factor and offers a maximum transmission speed of 100Gbps over a single wavelength of 1310nm. This transceiver is engineered with superior quality components and advanced technologies to ensure reliable data transfer over long distances. The transceiver features a high-performance transmitter and receiver, which are enclosed in an EMI-resistant housing. Moreover, it is designed with a high-density connector interface that helps reduce the size of the module and provides easier installation. The transceiver is also backed by a 3-year warranty and is compatible with various network switches and routers.
| Property | Value |
|---|---|
| Product Name | 100G QSFP28 Transceiver |
| DDM | YES |
| Fiber Type | Single-Mode |
| Data Rate | 100G |
| Application | Data Center/Telecom Network |
| Wavelength | 1310nm |
| Temperature | 0~70°C |
| Connector | QSFP28 |
| Distance | 30km |
| Warranty | 3 Years |
| Parameter | Symbol | Min | Typ. | Max | Unit |
| Transmitter | |||||
| Center Wavelength | λ |
1294.53 1299.02 1303.54 1309.09 |
1295.56 |
1296.59 1301.09 1305.63 1310.19 |
nm |
| 1300.05 | |||||
| 1304.58 | |||||
| 1309.14 | |||||
| Side-mode Suppression ratio | SMSR | 30 | - | - | dB |
| Average Optical Power, each Lane | Pavg | -2.5 | - | 6.5 | dBm |
| Extinction Ratio | ER | 4.5 | - | - | dB |
| Optical Modulation Amplitude (OMA), (Each Lane) | OMA | 0.5 | - | 6.5 | dBm |
| Transmitter Eye Mask Definition | {0.25, 0.4, 0.45, 0.25, 0.28, 0.4} | ||||
| Average Launch Power OFF Transmitter, each Lane | Poff | - | - | -30 | dBm |
| Transmitter and Dispersion Penalty (Each Lane) | TDP | 3 | dB | ||
| Optical Return Loss Tolerance | ORLT | 20 | dB | ||
|
Receiver |
|||||
| Center Wavelength | λ |
1294.53 1299.02 1303.54 1309.09 |
1295.56 |
1296.59 1301.09 1305.63 1310.19 |
nm |
| 1300.05 | |||||
| 1304.58 | |||||
| 1309.14 | |||||
| Receiver sensitivity (OMA), each lane at 5 x 10-5 BER | - | -18.5 | dBm | ||
| Stressed receiver sensitivity (OMA), each lane | -16 | dBm | |||
| Damage threshold, each lane | -2.5 | dBm | |||
| Average Receive Power (Each Lane) | -20.5 | -3.5 | dBm | ||
| Receiver Reflectance | - | - | -26 | dB | |
Data center interconnection: 100G QSFP28 ER4 Lite module can be used to connect network equipment between different data centers to achieve high-speed, reliable data transmission and support long-distance interconnection between data centers.
Long-distance optical fiber network: Since 100G QSFP28 ER4 Lite supports long-distance transmission, it can be used to build a wide area network (WAN) across cities or regions to achieve high-speed data transmission and long-distance communications.
Telecom operator networks: Telecom operators can use 100G QSFP28 ER4 Lite modules to expand their fiber optic networks to provide high-speed broadband access, data transmission and interconnection services.
Video transmission and streaming media: For applications that need to transmit large amounts of high-definition video or streaming media content, 100G QSFP28 ER4 Lite can provide high bandwidth and stable transmission performance to ensure fast transmission of video content.
Transmission distance and rate: QSFP28 modules usually have different variants, such as SR4, LR4, ER4, etc., for different transmission distance and rate requirements. You can work with suppliers to customize QSFP28 modules to meet your specific transmission distance and rate requirements. , such as increasing transmission distance or providing higher rate support.
Optical characteristics: Based on your needs, you can customize the optical characteristics of the QSFP28 module, such as wavelength range, modulation method, etc. This can be adjusted according to the specific optical fiber infrastructure and transmission environment to ensure the best optical performance and compatibility .
Special environmental requirements: If you use the QSFP28 module in a special environment, such as high temperature, low temperature, high humidity or radiation-resistant environment, you can work with your supplier to customize the QSFP28 module to adapt to these special environmental requirements.
Specific protocol support: If you need specific protocol support, such as Ethernet, Fiber Channel, InfiniBand, etc., you can customize the QSFP28 module to meet the requirements of these specific protocols.
Other customized needs: According to your specific needs, you can also customize other aspects of the QSFP28 module, such as power consumption, interface type, monitoring and diagnostic functions, etc.
We provide comprehensive technical support and service for our 100G QSFP28 Transceiver products. Our technical support staff is available 24/7 to answer your questions and provide assistance with installation and maintenance.
We provide detailed documentation and tutorial resources to help you get the most out of your 100G QSFP28 Transceiver. Our step-by-step guides and tutorials make it easy to understand the features and functions of our products.
In the unlikely event of a hardware failure, we offer a free repair service. Our technicians can quickly diagnose and repair any hardware issue with your 100G QSFP28 Transceiver.
We also offer a comprehensive warranty on all of our products. In the event of a defect, we will provide a replacement part at no cost.
If you have any questions about our 100G QSFP28 Transceiver products or services, please don't hesitate to contact us.
Packaging and Shipping for 100G QSFP28 Transceiver:
The 100G QSFP28 Transceiver will be packaged in the original manufacturer's box, and then wrapped in bubble wrap for extra protection. It will then be placed in a cardboard box for shipping.
The box will be shipped via a reputable shipping company, and will include tracking information and insurance.
Reference Datasheet file code:DS090006 (100G QSFP28 ER4 Lite)
