TPB-TG40-23DCR 10G 40km TX1270nm,RX1310nm BIDI Duplex SFP+ Transceiver Module for Networking
The Small Form-Factor Pluggable Plus Transceiver Module (SFP+ Transceiver Module) is designed to provide reliable data transfer at ultra-high speeds of up to 10Gbps for single-mode fiber. This module comes with Digital Diagnostic Monitoring (DDM) / Digital Optical Monitoring (DOM) and a wavelength of TX1270nm / RX1310nm. It is designed to operate in a temperature range of -5~70°C, allowing for a wide range of applications.
The SFP+ Transceiver Module is ideal for high speed, high bandwidth applications, such as Ethernet, Fibre Channel, Infiniband and SONET/SDH. It provides superior performance and reliable data transmission even in the harshest of environments.
The SFP+ Transceiver Module is a cost-effective, efficient and reliable solution for data transfer over long distances. With its advanced features and temperature range of -5~70°C, it is the perfect choice for any high speed, high bandwidth application.
| Product Name | Specification |
|---|---|
| Fiber Type | Single-Mode |
| Compliant Code | MSA SFF-8472 |
| Connector Type | LC |
| Distance | 40km |
| Data Rate | 10Gbps |
| DDM/DOM | Yes |
| Wavelength | TX1270nm/RX1310nm |
| Product Name | SFP+ Transceiver Module |
| Cable Type | Duplex |
| Temperature Range | -5~70°C |
| Parameter | Symbol | Min | Typ. | Max | Unit |
| Transmitter | |||||
| Centre Wavelength | λc | 1260 | 1270 | 1280 | nm |
| 1320 | 1330 | 1340 | nm | ||
|
Side Mode Suppression Ratio |
SMSR | 30 | - | - | dB |
| Spectral Width (-20dB) | Δλ | - | - | 1 | nm |
| Average Output Power*note6 | Pout | +1 | - | +6 | dBm |
| Extinction Ratio | ER | 3.5 | - | - | dB |
| Average Power of OFF Transmitter | Pout-off | - | - | -30 | dBm |
| Transmitter Dispersion Penalty | TDP | - | - | 2 | dB |
| Relative Intensity Noise | RIN | - | - | -128 | dB/Hz |
| Output Optical Eye | Compliant with IEEE802.3ae-2005 | ||||
| Receiver | |||||
| Centre Wavelength | λc | 1320 | - | 1340 | nm |
| 1260 | - | 1280 | nm | ||
| Receiver Sensitivity*note7 | SEN | - | - | -15 | dBm |
| Receiver Overload | Pmax | 0 | - | - | dBm |
| LOS De-Assert | LOSD | - | - | -18 | dBm |
| LOS Assert | LOSA | -30 | - | - | dBm |
| LOS Hysteresis | LOSH | 0.5 | - | 4 | dB |
Data centers: In high-density data centers, this commercial-grade transceiver module can be used to connect servers, storage devices, network switches, etc. for fast and reliable data transmission. It supports high-speed Ethernet protocols such as 10GBASE-LR/LW, which is suitable for long-distance connection needs of data centers.
Enterprise Networks: In enterprise networks, this commercial-grade module can be used to establish reliable network connections. It can connect enterprise network equipment, such as switches, routers and firewalls, to achieve high-speed data transmission and network expansion.
Financial Transactions: In financial transactions, this commercial-grade transceiver module provides high-speed, low-latency data transmission. It can be used to connect trading servers, trading platforms and market data systems to ensure fast and reliable trade execution.
Telecommunications Operators: As part of telecommunications infrastructure, this commercial grade module can be used in fiber optic communication networks. It can be used to connect optical fiber transmission equipment, optical fiber switches and optical fiber access equipment, supporting high-speed, long-distance data transmission.
Video Surveillance: In video surveillance systems, this commercial-grade transceiver module can be used to transmit high-definition video signals. It can connect cameras, surveillance video recorders and video management systems, supporting long-distance video transmission and monitoring.
Transmission Distance: The module's default transmission distance is 40km, but it can be customized to support shorter or longer distances based on specific requirements. For example, it can be adjusted to support 20km or 60km transmission distances.
Wavelength: The module operates at TX1270nm and RX1310nm wavelengths by default. However, customization may allow for different wavelength combinations to meet specific network setups or compatibility needs.
Power Budget: The power budget of the module can be customized to meet specific link budget requirements. This ensures optimal performance and compatibility with the network infrastructure.
Digital Diagnostics Monitoring (DDM): The module can be customized with DDM functionality, which provides real-time monitoring of key parameters such as optical power, temperature, and voltage. This customization option allows for enhanced network management and troubleshooting capabilities.
Connector Type: The module can be customized with different connector types based on the network infrastructure. Common options include LC, SC, or MPO connectors to ensure seamless integration with existing equipment.
Labeling and Branding: Customization can extend to the labeling and branding of the module. Customers may request specific labels, logos, or branding elements to align with their own branding standards or requirements.
Compatibility and Protocol Support: The module can be customized to support various protocols, such as Ethernet, Fibre Channel, or SONET/SDH, depending on the customer's specific network requirements.
SFP+ Transceiver Module offers a wide range of technical support and services to ensure customers have the best possible product experience.
Our technical support team is available to provide assistance with installation, troubleshooting, and product-related questions. Our team is available 24/7 and can be contacted via telephone, online chat, or email.
We provide a wide range of services, including firmware updates, product customization, and product upgrades. We also offer training and technical support for our products.
Our services are designed to ensure our customers have the best possible product experience and are always up-to-date with the latest product features and functionality.
SFP+ Transceiver Module Packaging and Shipping
