Product Details:
|
| Product Name: | 1080P Fiber Optical Video Converter With 1CH RS485 Data | BNC Port: | 8Ch BNC Port |
|---|---|---|---|
| Wavelength: | 1310/1550nm | Operating Temperature: | 0℃ To +70℃ |
| Application: | FTTH FTTB FTTX Network | Data: | 1Ch RS485 Data |
| Transmission Distance: | 20/40/60/80/km | Warranty: | 3 Years |
| High Light: | FTTX Network rs485 fiber converter,8CH Fiber Optic Video Converter,FTTH Fiber Optic Video Converter |
||
Miray's 8Ch AHD/CVI/TVI/CVBS Fiber optic transceiver can simultaneously transmit 8 channels AHD, HD-CVI, HD-TVI or CVBS Video over one multimode or single-mode optical fiber. Electronic and optical adjustments are never required. LED indicators are provided for instantly monitoring system status. Devices are available for either standalone or rack-mount installation, which is suitable for different working environment. It supports input video format as 25/30/50/60fps@720P & 25/30fps@1080P.
Features
City traffic monitoring system
Public security, safe city monitoring system
Highway security protection, charging system
Building, campus monitoring net
Industrial monitoring (airport, chemical industrial, steel, oil, railway, water conservancy, mine, etc)
Military monitoring (storehouse, frontier defense, guard, nation defense, etc)
Electric power, oilfield, television program transmission system
|
Feature |
Description |
|
|
|
Fiber Type |
Multi-mode fiber or Single mode fiber |
|
Fiber Connector |
FC/ST/SC |
|
|
Distance |
0~80km (Optional) |
|
|
Wavelength |
Transmitter |
|
|
|
Input level |
>500mVp-p |
|
self-adaption cable equilibrium |
1080p:75-5 |
|
|
Input/Output Impedance |
75Ω |
|
|
Physical Interface |
1/2/4/8 channel BNC connector |
|
|
|
Output level |
1Vp-p |
|
Input/Output Impedance |
75Ω |
|
|
Physical Interface |
1/2/4/8 channel BNC connector |
|
|
|
Transmission Media |
Terminal blocks Data cable |
|
Baud Rate |
1200～9600bit/s |
|
|
Bit Error Rate |
≦10 |
|
|
Operation Mode |
Half-Duplex |
|
|
Indicators |
LOS,PWR,DATA,VIDEO |
|
|
Mean time between failures (MTBF) |
＞100 000 hours |
|
|
|
EPS |
DC5V |
|
Power Consumption |
≦5W |
|
|
Operation Temperature |
-40℃～75℃ |
|
|
Operation Humidity |
10%～90% |
|
|
Atmospheric Pressure |
86kpa~106kpa |
|
|
Mounting Method |
Wall-mounted |
|
|
Data |
Physical interface: Industrial standard terminal |
|
Audio |
Connector: Terminal Blocks |
|
Telephone |
Connector: RJ11 |
|
Ethernet |
Connector: RJ45 |
|
Contact Closure |
Physical connector: Industrial standard connector port |
|
Optical Budget |
Multi-mode / 20dBm / 2KM |
|
Model |
Description |
|
MR-8V-F20-720P |
720P AHD/TVI/CVI Fiber Video Converter,single mode single fiber , 8CH video, 20KM, FC, Iron, 1V↑ |
|
MR-8V1D-F20-720P |
720P AHD/TVI/CVI Fiber Video Converter,single mode single fiber, 8CH video+ reverse data, 20KM, FC, Iron, 1V↑+1D↓ |
|
MR-8V-F20-1080P |
1080P AHD/TVI/CVI Fiber Video Converter,single mode single fiber , 8CH video, 20KM, FC, Iron, 1V↑ |
|
MR-8V1D-F20-1080P |
1080P AHD/TVI/CVI Fiber Video Converter,single mode single fiber, 8CH video+ reverse data, 20KM, FC, Iron, 1V↑+1D↓ |
Product Show
