Product Details:
|
| Product Name: | 10GBASE-LR SFP+ Transceiver Module | Rate: | 10G |
|---|---|---|---|
| Wavelength: | 1310nm | Fiber Type: | SMF |
| Application: | Telecommunication, Gigabit Ethernet, FTTH FTTB FTTO Network, | Compatible: | Cisco, Huawei, HP, Finisa, Arista |
| Certification: | CE RoHS FCC ISO9001 | Warranty: | 3 Years |
This Arista Networks SFP-10G-LRL compatible SFP+ transceiver provides 10GBase-LRL throughput up to 1km over single-mode fiber (SMF) at a wavelength of 1310nm using a LC connector. It is guaranteed to be 100% compatible with the equivalent Arista Networks transceiver.
This easy to install, hot swappable transceiver has been programmed, uniquely serialized and application tested to ensure that it will initialize and perform identically to the OEM Transceiver. Digital optical monitoring (DOM) support is also present to allow access to real-time operating parameters.
|
Parameter |
Symbol |
Unit |
Min |
Typ |
Max |
|
Operating Case Temperature Range |
Tc |
oC |
0 |
|
70 |
|
Power Supply Voltage |
Vcc |
V |
3.14 |
3.3 |
3.46 |
|
Bit Rate |
BR |
Gb/s |
|
|
10.52 |
|
Bit Error Ratio |
BER |
|
|
|
10-12 |
|
Max Supported Link Length |
L |
Km |
|
|
10 |
|
Parameter |
Symbol |
Min |
Typ |
Max |
Note |
Unit |
|
Optical Transmitter Characteristics |
||||||
|
Nominal Wavelength |
λ |
|
1310 |
|
|
nm |
|
Optical Output Power |
Pav |
-6 |
|
2 |
|
dBm |
|
Extinction Ratio |
ER |
3.5 |
|
|
|
dB |
|
Average Launch Power of OFF Transmitter |
POFF |
|
|
-35 |
|
dBm |
|
Relative Intensity Noise |
RIN |
|
|
-128 |
|
dB/Hz |
|
Optical Receiver Characteristics |
||||||
|
Center Wavelength |
λC |
1260 |
|
1620 |
|
nm |
|
Receiver Sensitivity@10.3Gb/s |
RSENSE |
|
|
-14.4 |
1 |
dBm |
|
Receiver Overload |
|
0.5 |
|
|
|
dBm |
|
Optical Return Loss |
|
27 |
|
- |
|
dB |
|
LOS Assert |
LOSA |
-30 |
|
|
|
dBm |
|
LOS De-Assert LOS |
LOSD |
|
|
-17 |
|
dBm |
|
LOS Hysteresis |
|
0.5 |
|
|
|
dB |
