Product Details:
|
| Product Name: | Gigabit SFP Fiber Media Converter | Data Rate: | 10/100/1000Mbps |
|---|---|---|---|
| Fiber Type: | SFP Slot | Distance: | 0~120km |
| Wavelength: | 850nm/1310nm/1550nm | Operating Temperature: | 0℃ To +70℃ |
| Connector: | SC/ST | Warranty: | 3 Years |
| High Light: | 100base Fx Media Converter,1550nm Gigabit Fiber Media Converter,SFP Gigabit Fiber Media Converter |
||
Miray SFP media converters are providing the flexibility of 10/100/1000Mbps Ethernet Media via RJ45 port and highly stable Gigabit fiber performance, the MR-1001SFP media converter support conversion between 10/100/1000BASE-T and 100/1000BASE-X network. There are SFP connectors which allows the distance to be adjustable. The Ethernet signal allows three types of segments to connect easily, efficiently and inexpensively.
Supporting inter-conversion between 10/100/1000Base-TX and 1000Base-SX/LX
Supporting full-duplex and half-duplex and auto-negotiation
Supporting automatic cross connection of twisted pair interfaces, facilitating system commissioning and installation
Supporting the transmission of extra-long VLAN packets
Supporting Quality of Service (QoS) and ensuring the transmission of VoIP packets;
Supporting STP to form a redundant network
|
Model |
MR-1001SFP |
|
|
Optical Interface |
Connector |
SFP Slot |
|
|
Data Rate |
1000Mbps |
|
|
Duplex Mode |
Full duplex |
|
|
Fiber |
MM 50/125um,62.5/125um SM 9/125um |
|
|
Distance |
10/100/1000Mbps: MM 550m/2km,SM 20/40/60/80km |
|
|
Wavelength |
MM 850nm,1310nm SM 1310nm,1550nm WDM Tx1310/Rx1550nm(A side),Tx1550/Rx1310nm(B side) WDM Tx1490/Rx1550nm(A side),Tx1550/Rx1490nm(B side) |
|
UTP Interface |
Connector |
RJ45 |
|
|
Data Rate |
10/100/1000Mbps |
|
|
Duplex Mode |
Half/full duplex |
|
|
Cable |
Cat5,Cat6 |
|
Power Input |
Adapter Type |
DC5V |
|
|
Power Built-in Type |
AC100~240V |
|
Weight |
Adapter Type |
0.39kg |
|
|
Power Built-in Type |
0.67kg |
|
Dimensions |
Adapter Type |
94*70.5*26.5cm |
|
|
Power Built-in Type |
140.5*111*30cm |
|
Power Consumption |
<3W |
|
|
Temperature |
0~50℃ Operating; -40~70℃ Storage |
|
|
Humidity |
5~95%(no condensing) |
|
|
MTBF |
≥10.0000h |
|
|
Certification |
CE,FCC,RoHS |
|
|
Warranty |
3 years warranty |
|
|
Part Number |
Description |
| MR-1001S20 | 10/100/1000M Dual fiber SM 20KM SC External Power Supply |
| MR-1001SFP | 10/100/1000M SFP Slot Media Converter External Power Supply |
|
MR-1001S20AB |
10/100/1000M Single fiber SM 20KM SC External Power Supply |
|
MR-1001S40AB |
10/100/1000M Single fiber SM 40KM SC External Power Supply |
|
MR-1001S60AB |
10/100/1000M Single fiber SM 60KM SC External Power Supply |
|
MR-1001S80AB |
10/100/1000M Single fiber SM 80KM SC External Power Supply |
